• Form factor: M.2 2280
• Host interface: Serial ATA interface with 6.0 Gbps
• Operating temperature: 0 °C to 70 °C
• Storage temperature: -40 &deg,C to 85 &deg,C
• Humidity: 5% to 95%, non-condensing
• Sto&szlig,: 1500&nbsp,G, duration 0.5&nbsp,ms half pulse
• Vibration: 7 Hz~800 Hz, 3.08 Grms, 30 min/axis (X, Y, Z)
• Dimensions: 80 mm x 22.1 mm x 2.3 mm
• Weight: 9.1 g

Data transfer speed:

• Read speeds: 256 GB: up to 520 MB/s* / 512 GB: up to 520 MB/s* / 1 TB: up to 520 MB/s*
• Write speeds: 256 GB: up to 470 MB/s* / 512 GB: up to 480 MB/s* / 1 TB: up to 490 MB/s*

Power consumption:

• Active reading power consumption: 256 GB: 1400 mW / 512 GB: 1430 mW / 1 TB: 1800 mW
• Power consumption during active writing: 256 GB: 1450 mW / 512 GB: 1390 mW / 1 TB: 1600 mW
• Power consumption in idle mode: 256 GB: 450 mW / 512 GB: 600 mW / 1 TB: 620 mW

Designed for use in client PC applications, but not in server environments.

*Based on internal test result. Performance may vary depending on host drive.
