DrayTek's new Supervectoring VDSL modem
The DrayTek Vigor 167 is a modem for Supervectoring Profile 35b and all common VDSL and ADSL variants
From profile 17a, with and without vectoring, up to DSL-Light with 384 KBit/s.
The modem is designed for both older connections and the new All-IP BNG connections
If your device does not support VLAN tagging, our Vigor167 modem will compensate for this
and can do the tagging for you.
The DrayTek Vigor 167 replaces the Vigor 165, the Vigor166 remains available as a G.Fast modem.
to do with the fact that there is no chipset that supports ADSL and G.Fast simultaneously, since both have a similar
frequency spectrum and interference could occur.
Thus, there is the Vigor167 for ADSL/VDSL/Supervectoring connections, the Vigor166 serves G.Fast
Connections with 106MHz and 212MHz.
The Vigor167 comes with a new chipset and now supports Annex-A and Annex-B in one
Device. All variants of DSL connection cables for various regions are already included in the delivery
included. For example TAE-F to RJ11 cable, RJ11 to RJ11 cable, RJ11 to RJ45 cable.
In the delivery state, the Vigor167 as a pure modem is already set so that the VLAN Tag 7 from
Modem. Your subsequent dial-up router no longer needs to set a VLAN tag. If your ISP
use a different VLAN tag, please change the value of the VLAN tag in the modem's web interface
accordingly.
A future firmware update will add an optional router mode, which will be available in the
Web interface can be optionally activated. This gives the administrator the option to
the web interface as a router, which allows various dial-in options, port forwarding,
DHCP server and other features are enabled.
The modem has 2 Gigabit Ethernet LAN ports. Your existing network structure can be
can be integrated quickly and easily. For example, if you have your dial-up router connected via LAN Port 1
connected, you can continue to access our modem via LAN Port 2, for example
Status information to monitor. With IPv6 and VLAN technologies for triple play, current and
future technologies are already supported.

scope of delivery
Included accessories
- 1x drilling template for wall mounting
- 2x screws / 2x dowels for wall mounting
- 1x power supply
- 1x Ethernet cable
- 1x Quick Start Guide

DSL connection cable:
- 1x TAE to RJ11
- 1x RJ11 to RJ11
- 1x RJ11 to RJ45
