offline technology

Energy-saving power supply protection for workstations

The LCD screen of the Eaton Ellipse PRO not only clearly displays the system status and measured values, it also makes it easier to configure the desired UPS settings.

The EcoControl function automatically deactivates the peripheral devices when the master device is switched off, thereby achieving energy savings of up to 20%.

The Automatic Voltage Regulation (AVR) corrects voltage fluctuations immediately, so work can continue without battery operation if voltage drops or overvoltages occur.

The Ellipse PRO has high performance surge protection according to IEC 61643-1. It also protects data transmissions over Ethernet, Internet and telephone connections.

&nbsp,

Easy integration and installation

The Ellipse PRO is optionally equipped with four (for 650/850 VA) or eight (for 1200/1600 VA) Schuko (DIN) or IEC socket outlets. This makes it easy to connect standard computer configurations with peripheral devices.

Due to its extra-flat design, the Ellipse PRO can be easily installed in any office environment. The deployment options include vertical installation (e.g. under the desk), horizontal installation (e.g. under the monitor), 19 inch rack mounting (optional 2U mounting kit) and wall mounting (optional mounting kit).

The Ellipse PRO is equipped with a USB port and comes complete with a USB cable and Eaton UPS Companion software, which ensures safe system shutdown, energy consumption tracking and easy configuration of UPS settings.

&nbsp,

Comprehensive security

Three-year warranty, including on batteries.

Unlimited warranty for the connected computer equipment (only in EU countries and Norway).

The batteries undergo automatic self-tests at regular intervals, ensuring timely detection of batteries that need to be replaced.

Easily replaceable batteries help increase the lifespan of the UPS.
